AGL
Sliding · industrial
DZ Strong
The heavy-duty sliding operator: up to 2,000 kg and 120 cycles an hour.
2,000 kgmax gate weight
120/hmax cycles per hour
3models in the line
DZ Strong is built for factory, warehouse and compound gates that open all day. It has metal internal gearing and the control board is built into the machine, so there is no separate box to mount and wire. Every model runs on a single-phase supply.
220 V · 50 HzGulf supply version
Aerial mount optionlifts the motor above standing water
Metal gearingfor heavy, frequent use
- Gates up to 2,000 kg
- Up to 120 cycles per hour
- Metal internal gearing
- Control board built in
- Single-phase supply
- Electronic brake and anti-trap system
AGL codes: 2001299
Spec sheet
AGL published data · 220 V for the Gulf| Model | Gate weight | Opening | Cycles / hour | Motor | Notes |
|---|---|---|---|---|---|
| DZ Strong 1000 | up to 1,000 kg | 3 m in ~12 s | 60 | 1/2 HP | Metal gear |
| DZ Strong 1500 | up to 1,500 kg | 3 m in ~12 s | 80 | 3/4 HP | Metal gear |
| DZ Strong 2000 | up to 2,000 kg | 3 m in ~12 s | 120 | 1 HP | Metal gear |
More sliding operators
See all
Have a gate to automate?
Send the gate type, weight and how often it opens. We reply with the right AGL operator, a price and the lead time from Dubai.
